DL 05 CPU, 8 AC in / 6 AC out, with 110/230 VAC power supply

Ref: D0-05AA

DL05 CPU, 8 AC in / 6 AC out, 110/230 VAC power supply. 6K words total (2048 words ladder - flash, 4096 words V-memory), RLL/RLLPLUS programming, built-in RS232C programming port and additional RS232C communications port. Inputs: 8 AC inputs, 90-120 VAC, 2 isolated commons. Outputs: 6 AC outputs, 17-240 VAC, 0.5A/pt. max., 2 isolated commons. One option slot available for I/O or communication module.
